| Nominal Voltage [V] | 51.2 |
| Nominal Capacity [Ah] | 200 |
| Total Energy [kWh] | 10.24 |
| Max. Charging Continuous Current [A] | 150 |
| End Of Charging Voltage [V] | 57.6 |
| Max. Discharging Continuous Current [A] | 150 |
| End Of Discharge Voltage [V] | 44.8 |
| Dimension (W*D*H,mm) | 150*560*865 |
| Weight [Kg] | 83 |
| Protection Class | IP20/IP55 |
| Operation Humidity | 0~95%RH (No Condensing) |
| Operating Temperature Range | Charge:0~+55℃；Discharge:-20℃~+60℃ |
| Cycle Life | 5000 @25℃, 0.5C, 90%DOD, 80%EOL 6000 @25℃, 0.5C, 90%DOD, 70% EOL |
| Protection | Over Charge, over Discharge, Over Current , Over Temperature And Low Temperature Protection |
| MOFEST | Automatic Cutting Out |
| Communication Port | RS485 & CAN (Pack To Pcs), RS485 (Pack To Pack) |
| Certification | UN38.3, MSDS |
| Serial Support | No Support |
| Parallel Support | Yes, Max 10 PCS |
| Optional Parts | Heater |
| Connecting Terminal | 180A, 4P |
| Circuit Breaker | 125A, 2P |
