| Nominal Voltage [V] | 25.6 |
| Nominal Capacity [Ah] | 100 |
| Total Energy [kWh] | 2.56 |
| Max. Charging Continuous Current [A] | 100 |
| End of charging voltage [V] | 28.8 |
| Max. Discharging Continuous Current [A] | 100 |
| End of discharge voltage [V] | 22.4 |
| Dimension (W*D*H,mm) | 245*530*145 |
| Weight [Kg] | 20 |
| Protection class | IP20 |
| Operation Humidity | 0~95%RH (No Condensing) |
| Operating Temperature Range | Charge:0~+55℃；Discharge:-20℃~+60℃ |
| Cycle Life | 5000 @25℃, 0.5C, 90%DOD, 80%EOL 6000 @25℃, 0.5C, 90%DOD, 70%EOL |
| Protection | Over Charge, Over Discharge, Over Current, Over Temperature and Low Temperature Protection |
| MOFEST | Automatic Cutting Out |
| Communication Port | RS485 & CAN (Pack To Pcs), RS485 (Pack To Pack) |
| Certification | UN38.3, MSDS |
| Serial Support | No Support |
| Parallel Support | Yes, Max 15 PCS |
| Optional Parts | Heater |
| Connecting Terminal | 100A, 4P |
| Circuit Breaker | 125A, 1P |
